MaxiDAS DS900 EU
Product information
£825.00 excl. VAT
Product Description
The MaxiDAS DS900 EU stands as an 8-inch touchscreen device that serves as an all-systems scanner and service tablet for automotive professionals. This robust, wired tablet possesses the capability to read and clear fault codes, examine Freeze Frame data, display and chart Live Data, and carry out bi-directional Active Tests and Special Functions.
Notably, the MaxiDAS DS900 EU is a comprehensive service tablet offering more than 40 service and maintenance functions. This includes tasks such as Brake Bleeding, Oil and Service Light Resets, Battery Registration, DPF Regeneration, and Electronic Parking Brake and Steering Angle adjustments.
Running on the Android 11 operating system and equipped with a 1.8 GHz processor, the MaxiDAS DS900 EU ensures smooth and efficient operation. Additionally, it comes bundled with 2 year's worth of software updates and a 2 year limited warranty, further enhancing its value to automotive professionals.
Product Comparison
MaxiDAS DS900 EUBT
£995.00 excl. VAT
|
MaxiSYS MS906S Pro EU
£1,795.00 excl. VAT
|
MaxiSYS MS909
£2,995.00 excl. VAT
|
MaxiSYS MS919
£3,995.00 excl. VAT
|
MaxiSYS Ultra
£5,250.00 excl. VAT
|
|
| CPU | Rockchip RK3566 Quad corex 4 x 1.8GHz | Qualcomm Octa-Core 2.3GHz + 1.7GHz | Samsung Exynos 8859v Octa-Core 2.3GHz + 1.7GHz | Samsung Exynos 8859v Octa-Core 2.3GHz + 1.7GHz | Samsung Exynos 8859v Octa-Core 2.3GHz + 1.7GHz |
|---|---|---|---|---|---|
| Operating System | Android 11 | Android 10 | Android 7.0 | Android 7.0 | Android 7.0 |
| Device Memory | 64GB SSD / 4GB RAM | 128GB SSD / 4GB RAM | 128GB SSD / 4GB RAM | 128GB SSD / 4GB RAM | 256GB SSD / 4GB RAM |
| Captive Touch-screen | 8" 1024x768DPI / TFT-LCD Touch-screen | 8" 1920x1200DPI / TFT-LCD Touch-screen | 9.7" 2048x1536DPI / TFT-LCD Touch-screen | 9.7" 2048x1536DPI / TFT-LCD Touch-screen | 12.9" 2732x2048 DPI / TFT-LCD Touch-screen |
| Connectivity | USB 2.0 Mini USB 2.0 Wi-Fi | USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a | USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a | USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a | USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a |
| Wi-Fi | 2.4 GHz | 2.4 GHz | 2.4 GHz | 2.4 GHz | 2.4 GHz |
| Internal Lithium Battery | 7700mAh 3.7V Lithium battery | 11600 mAh 3.7V Lithium battery | 15000 mAh 3.7V Lithium battery | 15000 mAh 3.7V Lithium battery | 18000 mAh 3.7V Lithium battery |
| Weight | 1.35kg | 1.42kg | 1.42kg | 1.42kg | 1.89kg |
| Camera | REAR 8.0 Mega-pixel AF | REAR 16.0 Mega-pixel AF with flash + 5MP FRONT | 16.0 Mega-pixel AF with flash | 16.0 Mega-pixel AF with flash | 16.0 Mega-pixel AF with flash |
| Oscilloscope | Optional Upgrade | ||||
| Multimeter | |||||
| Waveform Generator | |||||
| CAN Check | |||||
| Repair Assist | |||||
| Tech Bulletins | |||||
| DTC Analysis | |||||
| Relevant Cases | |||||
| System Topology | |||||
| Split Screen Function for same time Diag/Scope View | |||||
| ECU Coding with J2534 Included | |||||
| Coverage of European, US-American Asian vehicles | |||||
| Auto VIN reading | |||||
| MaxiFix Cloud System information | |||||
| Online Updates | |||||
| D-PDU Protocol Support | |||||
| RP1210 Protocol Support | |||||
| J2534 Protocol Support | |||||
| CANFD Protocol Support | |||||
| DoIP Protocol Support | |||||
| Docking Station | |||||
| ALL Modules - Chassis/Power Train/Body etc | |||||
| Read & Clear Diagnostic Fault Codes | |||||
| SAS/ABS/BMS/DPF Service Functions | |||||
| EPB & Steering Angle Calibration | |||||
| Service Mileage/Interval Reset | |||||
| Adaptions | |||||
| Actuation Testing | |||||
| Upgradable to ADAS | |||||
| Remote Expert | |||||
| Upgradeable to Borescope | |||||
| Upgrade with Battery Test Accessory | Optional Upgrade | Optional Upgrade | Optional Upgrade | Optional Upgrade | Optional Upgrade |
| Battery Analysation | Optional Upgrade | Optional Upgrade | |||
MaxiDAS DS900 EUBT
£995.00 excl. VAT
- CPU
- Rockchip RK3566 Quad corex 4 x 1.8GHz
- Operating System
- Android 11
- Device Memory
- 64GB SSD / 4GB RAM
- Captive Touch-screen
- 8" 1024x768DPI / TFT-LCD Touch-screen
- Connectivity
- USB 2.0 Mini USB 2.0 Wi-Fi
- Wi-Fi
- 2.4 GHz
- Internal Lithium Battery
- 7700mAh 3.7V Lithium battery
- Weight
- 1.35kg
- Camera
- REAR 8.0 Mega-pixel AF
- Oscilloscope
- Multimeter
- Waveform Generator
- CAN Check
- Repair Assist
- Tech Bulletins
- DTC Analysis
- Relevant Cases
- System Topology
- Split Screen Function for same time Diag/Scope View
- ECU Coding with J2534 Included
- Coverage of European, US-American Asian vehicles
- Auto VIN reading
- MaxiFix Cloud System information
- Online Updates
- D-PDU Protocol Support
- RP1210 Protocol Support
- J2534 Protocol Support
- CANFD Protocol Support
- DoIP Protocol Support
- Docking Station
- ALL Modules - Chassis/Power Train/Body etc
- Read & Clear Diagnostic Fault Codes
- SAS/ABS/BMS/DPF Service Functions
- EPB & Steering Angle Calibration
- Service Mileage/Interval Reset
- Adaptions
- Actuation Testing
- Upgradable to ADAS
- Remote Expert
- Upgradeable to Borescope
- Upgrade with Battery Test Accessory
- Optional Upgrade
- Battery Analysation
- Optional Upgrade
MaxiSYS MS906S Pro EU
£1,795.00 excl. VAT
- CPU
- Qualcomm Octa-Core 2.3GHz + 1.7GHz
- Operating System
- Android 10
- Device Memory
- 128GB SSD / 4GB RAM
- Captive Touch-screen
- 8" 1920x1200DPI / TFT-LCD Touch-screen
- Connectivity
- USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a
- Wi-Fi
- 2.4 GHz
- Internal Lithium Battery
- 11600 mAh 3.7V Lithium battery
- Weight
- 1.42kg
- Camera
- REAR 16.0 Mega-pixel AF with flash + 5MP FRONT
- Oscilloscope
- Optional Upgrade
- Multimeter
- Waveform Generator
- CAN Check
- Repair Assist
- Tech Bulletins
- DTC Analysis
- Relevant Cases
- System Topology
- Split Screen Function for same time Diag/Scope View
- ECU Coding with J2534 Included
- Coverage of European, US-American Asian vehicles
- Auto VIN reading
- MaxiFix Cloud System information
- Online Updates
- D-PDU Protocol Support
- RP1210 Protocol Support
- J2534 Protocol Support
- CANFD Protocol Support
- DoIP Protocol Support
- Docking Station
- ALL Modules - Chassis/Power Train/Body etc
- Read & Clear Diagnostic Fault Codes
- SAS/ABS/BMS/DPF Service Functions
- EPB & Steering Angle Calibration
- Service Mileage/Interval Reset
- Adaptions
- Actuation Testing
- Upgradable to ADAS
- Remote Expert
- Upgradeable to Borescope
- Upgrade with Battery Test Accessory
- Optional Upgrade
- Battery Analysation
- Optional Upgrade
MaxiSYS MS909
£2,995.00 excl. VAT
- CPU
- Samsung Exynos 8859v Octa-Core 2.3GHz + 1.7GHz
- Operating System
- Android 7.0
- Device Memory
- 128GB SSD / 4GB RAM
- Captive Touch-screen
- 9.7" 2048x1536DPI / TFT-LCD Touch-screen
- Connectivity
- USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a
- Wi-Fi
- 2.4 GHz
- Internal Lithium Battery
- 15000 mAh 3.7V Lithium battery
- Weight
- 1.42kg
- Camera
- 16.0 Mega-pixel AF with flash
- Oscilloscope
- Multimeter
- Waveform Generator
- CAN Check
- Repair Assist
- Tech Bulletins
- DTC Analysis
- Relevant Cases
- System Topology
- Split Screen Function for same time Diag/Scope View
- ECU Coding with J2534 Included
- Coverage of European, US-American Asian vehicles
- Auto VIN reading
- MaxiFix Cloud System information
- Online Updates
- D-PDU Protocol Support
- RP1210 Protocol Support
- J2534 Protocol Support
- CANFD Protocol Support
- DoIP Protocol Support
- Docking Station
- ALL Modules - Chassis/Power Train/Body etc
- Read & Clear Diagnostic Fault Codes
- SAS/ABS/BMS/DPF Service Functions
- EPB & Steering Angle Calibration
- Service Mileage/Interval Reset
- Adaptions
- Actuation Testing
- Upgradable to ADAS
- Remote Expert
- Upgradeable to Borescope
- Upgrade with Battery Test Accessory
- Optional Upgrade
- Battery Analysation
MaxiSYS MS919
£3,995.00 excl. VAT
- CPU
- Samsung Exynos 8859v Octa-Core 2.3GHz + 1.7GHz
- Operating System
- Android 7.0
- Device Memory
- 128GB SSD / 4GB RAM
- Captive Touch-screen
- 9.7" 2048x1536DPI / TFT-LCD Touch-screen
- Connectivity
- USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a
- Wi-Fi
- 2.4 GHz
- Internal Lithium Battery
- 15000 mAh 3.7V Lithium battery
- Weight
- 1.42kg
- Camera
- 16.0 Mega-pixel AF with flash
- Oscilloscope
- Multimeter
- Waveform Generator
- CAN Check
- Repair Assist
- Tech Bulletins
- DTC Analysis
- Relevant Cases
- System Topology
- Split Screen Function for same time Diag/Scope View
- ECU Coding with J2534 Included
- Coverage of European, US-American Asian vehicles
- Auto VIN reading
- MaxiFix Cloud System information
- Online Updates
- D-PDU Protocol Support
- RP1210 Protocol Support
- J2534 Protocol Support
- CANFD Protocol Support
- DoIP Protocol Support
- Docking Station
- ALL Modules - Chassis/Power Train/Body etc
- Read & Clear Diagnostic Fault Codes
- SAS/ABS/BMS/DPF Service Functions
- EPB & Steering Angle Calibration
- Service Mileage/Interval Reset
- Adaptions
- Actuation Testing
- Upgradable to ADAS
- Remote Expert
- Upgradeable to Borescope
- Upgrade with Battery Test Accessory
- Optional Upgrade
- Battery Analysation
MaxiSYS Ultra
£5,250.00 excl. VAT
- CPU
- Samsung Exynos 8859v Octa-Core 2.3GHz + 1.7GHz
- Operating System
- Android 7.0
- Device Memory
- 256GB SSD / 4GB RAM
- Captive Touch-screen
- 12.9" 2732x2048 DPI / TFT-LCD Touch-screen
- Connectivity
- USB 2.0 Mini USB 2.0 Dual Wi-Fi, HDMI 1.4a
- Wi-Fi
- 2.4 GHz
- Internal Lithium Battery
- 18000 mAh 3.7V Lithium battery
- Weight
- 1.89kg
- Camera
- 16.0 Mega-pixel AF with flash
- Oscilloscope
- Multimeter
- Waveform Generator
- CAN Check
- Repair Assist
- Tech Bulletins
- DTC Analysis
- Relevant Cases
- System Topology
- Split Screen Function for same time Diag/Scope View
- ECU Coding with J2534 Included
- Coverage of European, US-American Asian vehicles
- Auto VIN reading
- MaxiFix Cloud System information
- Online Updates
- D-PDU Protocol Support
- RP1210 Protocol Support
- J2534 Protocol Support
- CANFD Protocol Support
- DoIP Protocol Support
- Docking Station
- ALL Modules - Chassis/Power Train/Body etc
- Read & Clear Diagnostic Fault Codes
- SAS/ABS/BMS/DPF Service Functions
- EPB & Steering Angle Calibration
- Service Mileage/Interval Reset
- Adaptions
- Actuation Testing
- Upgradable to ADAS
- Remote Expert
- Upgradeable to Borescope
- Upgrade with Battery Test Accessory
- Optional Upgrade
- Battery Analysation
Product Features
- Extensive vehicle coverage for more than 70+ US, Asian and European vehicle makes.
- Exceptional OE-Level system coverage for all electronic systems.
- Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, etc.
Product Specification
- Android 11 OS Rockchip
- RK3566 Quad core Processor 4x 1.8GHz(A55)
- 64GB internal memory / 4 RAM
- Ultra fast Wi-Fi connectivity
- 8" 1024 x 768 high-resolution touch-screen
- 8 MP rear camera
- 7,000mAh Lithium-Polymer Battery
- Oil and Water screen resistant
- Wired connection to vehicle
- An up-to-date software subscription is required to access DoIP and CAN-FD systems.
- DoIP and CAN-FD Compliant
- Secure Gateway approved by Vehicle Manufacturers
